As the original "aluminum composite material," ALUCOBOND PLUS consists of two sheets of smooth .020" aluminum thermo-bonded to a solid, fire retardant core and has been developed exclusively to allow architects and designers to meet today's fire performance requirements set by the International Building Code (IBC) while using ACM as the material of choice. Proven product properties and benefits of ALUCOBOND PLUS include:
|
|
Or find us in these industry wide spec libraries.
Thickness | 4mm | |||
Width | 40" | 49.2" | 50" | 62" |
Length | 196" | 146" | 196" | 196" |
Solids | ||||
Micas / Metallics | ||||
Color-Changing | ||||
Textured | ||||
Reflective | ||||
Anodized | 1 | |||
Brushed | ||||
Prints |
Property | Standard | Unit | Value |
Thickness of Aluminum Skin | in | 0.020" (nominal) | |
Product Thickness | in / mm | 0.157" / 4mm (nominal) | |
Weight | lb/ft2 | 1.56 | |
Standard Width | in | 62" | |
Available widths / lengths | in | 40"-62" / 40"-400" | |
Flexural Modulus (Perpendicular) | ASTM D 790 | ksi | 1891 |
Flexural Modulus (Parallel) | ASTM D 790 | ksi | 6930 |
Modulus of Elasticity (Perpendicular) | ASTM D 638 | ksi | 2930 |
Tensile Yield at 0.2% Offset | ASTM D 638 | psi | 6570 |
Bond Integrity (pre/post artificial aging) | ASTM D 1781 | in-lb/in | >22.5 |
Coefficient of Linear Thermal Expansion | ASTM D 696 | in/in °F | 1.11x10-5 |
